Main
| Range of product | Phaseo Rectified |
| Product or component type | Power supply |
| Power supply type | Rectified and filtered |
| Rated power in W | 240 W |
| Input voltage | 230 V AC single phase, terminal(s): N-L1 400 V AC phase to phase, terminal(s): L1-L2 |
| Output voltage | 24 V DC |
| Power supply output current | 10 A |
| Operating position | Horizontal at 40 °C Vertical at 60 °C |
Complementary
| Input voltage limits | 360...440 V 207...253 V |
| Network frequency limits | 47…63 Hz |
| Input voltage tolerance | /- 15 V |
| Inrush current | 16 A at 230 V 9.24 A at 400 V |
| Cos phi | 0.783 at 230 V 0.834 at 400 V |
| Efficiency | 80 % |
| Power dissipation in W | 48 W |
| Residual ripple | <= 1200 MV |
| Holding time | 15 ms |
| Output protection type | Against overvoltage, protection technology: 2 J peak limiter Against overload and short-circuits, protection technology: external fuse, 12 A |
| Connections - terminals | For input connection: screw type terminals, connection capacity: 5 x 2.5...5 x 4 mm² AWG 14...AWG 11 For input ground connection: screw type terminals, connection capacity: 1 x 2.5...1 x 4 mm² AWG 14...AWG 11 For output connection: screw type terminals, connection capacity: 4 x 4 mm² AWG 11 |
| Marking | CE |
| Fixing mode | By 4 screws |
| Output coupling | Series Parallel |
| Operating altitude | 3000 m |
| Name of test | Conducted/radiated emissions conforming to EN 55011 class B Electrostatic discharges conforming to EN/IEC 61000-4-2 Emission conforming to EN 50081-1 Emission conforming to EN 61000-6-3 Rapid transient conforming to IEC 61000-4-4 Surge conforming to EN/IEC 61000-4-5 |
| Status LED | 1 LED (green)output voltage: 1 LED (orange)input voltage: |
| Depth | 185 mm |
| Height | 153 mm |
| Width | 123 mm |
| Net weight | 7.66 kg |
Environment
| Product certifications | CULus EAC UL 508 KC |
| Environmental characteristic | EMC conforming to IEC 62041 Safety conforming to EN/IEC 61558-2-6 Safety conforming to UL 508 Safety conforming to UL 60950-1 EMC conforming to EN/IEC 61000-3-2 |
| IP degree of protection | IP20 conforming to EN/IEC 60529 |
| Ambient air temperature for operation | -20…60 °C |
| Ambient air temperature for storage | -40…80 °C |
| Relative humidity | 0…95 % without condensation or dripping water |
| Electrical shock protection class | Class I conforming to VDE 0106-1 |
| Dielectric strength | 2000 V between input and ground 4600 V between input and output 500 V between output and ground |
Offer Sustainability
| Sustainable offer status | Green Premium product |
| REACh Regulation | |
| REACh free of SVHC | Yes |
| EU RoHS Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Mercury free | Yes |
| RoHS exemption information | |
| China RoHS Regulation | |
| Environmental Disclosure | |
| Circularity Profile | |
Contractual warranty
| Warranty | 18 months |
